SUS304 Food Conveyor Belt X Ray Scanner Machine

SUS304 Food Conveyor Belt X Ray Scanner Machine
SUS304 Food Conveyor Belt X Ray Scanner Machine SUS304 Food Conveyor Belt X Ray Scanner Machine SUS304 Food Conveyor Belt X Ray Scanner Machine

Large Image :  SUS304 Food Conveyor Belt X Ray Scanner Machine

Product Details:
Place of Origin: Guangdong Zhongshan China
Brand Name: TOUPACK
Certification: CE
Model Number: TTX-4080
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 10-25 working days
Payment Terms: T/T, L/C
Supply Ability: 30 sets per month

SUS304 Food Conveyor Belt X Ray Scanner Machine

Description
X-ray Light Source:: 150W/100KV Accuracy:: SUS Ball Φ0.3mm, SUS Wire Φ0.2*2mm
Transfer Speed:: 10-70m/ Min HMI:: 17 Inch Colorful Touch Screen
Connectivity:: LAN Port, USB Port X-ray Leakage:: 1 Millisievert / Hour
System: Windows 7 Power Supply: AC220V±10% 50Hz(60Hz) 1.5kVA Max
High Light:

Conveyor Belt X Ray Scanner Machine

,

SUS304 X Ray Scanner Machine

,

SUS304 Food X Ray Machine

X Ray Scanner Machine For Food With Conveyor Belt With Best Price For Food, Small Product Inspection



Application:



X-ray is special for bulk/loose products to detect the foreign matters from the products metallic, non-metallic contaminants (glass, ceramic, stone, bone, hard rubber, hard plastic, etc.)



Superior Performance
1. The equipment deliver effective product quality inspection for food, pharmaceutical, chemical and other industries, in addition to detecting contaminants such as metal, glass, bone, shell, hard rubber, hard plastic, it also inspects for products defects such as cracks, bubble, content defects etc. To achieve the complete finished product detection.
2. Excellent automatic detection capability, the accuracy of the metal contaminants such as the SUS ball can reach 0.5 mm.
3. It can be used to detect the contaminants in the metal packaging products and it will not be affected by temperature and humidity changes, to achieve the minimum error rate of the rejecting.

Security Design
Professional security design to achieve the innocuous high-accuracy inspection
1. X-ray Light
2. Lead-free protective curtain, which can be contacted with food directly
3. The monitoring of door's opening and closing
4. Emergency Stop Button

Security Guarantee
(1) Safety interlock stops X-ray output when the tunnel's integrity is compromised, such as a portion of operator's body is inserted
(2) X-ray emissions are under 1micro-sievert per hour to ensure the safety

Easy Operation
1. Simple and convenient touch-screen control to achieve efficient operations
2. Perfect data management system to achieve the easy saving of the product and image record.



Specifications:

Model TTX-4080
X-ray tube voltage MAX. 80kV, 100W
Belt Width 400
Conveyor Speed 10~60m/s
Screen Full-color TFT 15" Touch Screen
O/S Window XP Professional
Connectivity LAN port, USB port
Product Management Complete product log
Parameter Adjustment Auto learning/Manual learning
Image Management Auto image save/print/analyse
Power Supply 220V, AC
Body Material SUS304
Purification Easy to wash
Cooling method Compulsory air cooling/Air conditioned cooling
Operation temperature 0-35& deg; C (none conditioning)
Operation humidity 30-85%
X-ray emissions & lt; 1micro-sievert per hour
X-ray protection Lead/Lead-free protective curtain





SUS304 Food Conveyor Belt X Ray Scanner Machine 0SUS304 Food Conveyor Belt X Ray Scanner Machine 1SUS304 Food Conveyor Belt X Ray Scanner Machine 2

SUS304 Food Conveyor Belt X Ray Scanner Machine 3

SUS304 Food Conveyor Belt X Ray Scanner Machine 4SUS304 Food Conveyor Belt X Ray Scanner Machine 5SUS304 Food Conveyor Belt X Ray Scanner Machine 6
