Product Details:
|
Product Name: | Weighing And Packaging System For Blueberry | Control System: | MCU |
---|---|---|---|
HMI: | 10”color Touch Screen | Express: | DHL / FEDEX / UPS / TNT |
Shipping: | Ocean Shipping | Standard Export Port: | Zhongshan Port |
Delivery Type: | FOB,CIF,EXW | ||
High Light: | MCU Control Weighing And Packaging Machine,Blueberry Cherry Weighing And Packaging Machine,PU Belt Conveyor Linear Weigher |
MCU Control Weighing and Packaging System for Blueberry Cherry Tomatoes Raspberries PU Belt Conveyor
Application:
Application for weighing fruits and vegetables such as blueberries, cherry tomatoes and raspberries.
Developed for harsh packaging environments that require daily flushing procedures, the system operates at speeds of up to 150-200 boxes per minute.
Product Feature:
——Flexibility: Suitable for various small berry loading methods, automatic feeding, automatic weighing, online capping machine. Adapt to online labeling, coding, packing.
——Reliable system: Integrated self-developed control system to ensure reliability.
——Data storage: Large memory can store data for up to 99 jobs.
——Easy loading: Automatic Threading ™ This feature simplifies and speeds up specification conversion.
——Flushing capacity: IP65 rating to ensure safe operation.
——Adjustability: Timely adjustment, can be easily connected to the road equipment, fully automated operation.
——Sanitary design: The main components rotate to simplify cleaning and maintenance.
——Intuitive interface: the most advanced control system and friendly man-machine interface.
Overall Dimension:
Specifications:
Model |
TY-ZX122M100-01-11 |
Max. Weighing |
50-500g |
Accuracy |
X(0.5) |
Min. Scale Interval |
0.1g |
Max. Speed |
75 BPM |
Weighing Table Size |
100*100mm |
Power Supply |
AC220V/110V ±10% 50HZ/60HZ, 2KW |
Packing Dimension |
3300mm(L)*2400(W)*2000mm(H) |
Net Weight |
1085kg |
Package weight |
1200kg |
Functional characteristic:
Designed to meet high productivity requirements, the high speed high performance design provides a high speed pre-opened box conveyor for immediate loading, sealing.
The selection area of 1055mm wide adopts 930mm fishscale climbing belt, small Angle inclined design, easy to maintain and clean. Innovative coordinated motion tightness combined with a belt seal system ensures high quality, injury-free delivery. The system operates in continuous, intermittent or batch mode and cycles according to preset parameters, or manually using a foot switch. This highly flexible design fits one or more operators or feeders and a variety of product sizes.
An integrated control box with stepper motor and driver, an MCU and a 10-inch large panel view HMI is designed for ease of operation, maintainability, integration and overall system reliability. All the components are programmed using a simple flash memory card. Automatic touch control software displays production data in real time and provides easy access to job storage, job invocation, and on-board system diagnostics.
Authentic SidePocket® bags match the system for optimal performance and offer a variety of value-added features such as reclosing zippers, resealable flaps and tamper-proof perforations. Since the luggage is pre-made, there is no need for expensive modifications to the machine to take advantage of these features.
The back end of the high-speed box conveyor has a variety of equipment to choose from, can be preprinted in up to 10 colors, with high resolution graphics, text and bar codes, unique, beautiful packaging, has a competitive advantage.
>>Why choose us:
ㆍOver 12 years weighing and packing machine design & manufacturing experience
ㆍOver 60 countries customers choices
ㆍProfessional team with passion and diligence
ㆍAll-in-one stand service
After-sale services:
1. Manual / Videos of machine installation, adjusting, maintenance are available for you.
2. If any problems happened, telecom or online face to face communication available 24 hours.
3. Engineers & technician Engineer available to serve machines for your countries.
4. The machine will have 1 year warranty of machine.
FAQ:
Q1: Are you a manufacturer or a trading company?
A: We are manufacturer, we have professional factory in Guangdong China.
Q2. Do you sell the accessories for products?
A: Yes. We have Match the parts for our testing equipment.
Q3. How about the packing for product?
A: We takes of wooden case and it is very safe.
Q4. Do you accept customer Logo and customized?
A: we accept kinds of customized and logo of all of our products for customers.
Q5. What's your main product?
A: We are specialized in multi-head weigher, conveyor machine, packing machine, Metal detector, Check weigher and other related electronic products and machine.
Q6. How about your after-sales policy?
A: Customer First. We have our own R&D team and we can offer tech-support. All of our products normal warranty is 12months.
