32 Heads Mixing Small Granules Multihead Weigher

Certification
China GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD certification
China GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD certification
I'm Online Chat Now

32 Heads Mixing Small Granules Multihead Weigher

32 Heads Mixing Small Granules Multihead Weigher
32 Heads Mixing Small Granules Multihead Weigher
32 Heads Mixing Small Granules Multihead Weigher 32 Heads Mixing Small Granules Multihead Weigher 32 Heads Mixing Small Granules Multihead Weigher 32 Heads Mixing Small Granules Multihead Weigher 32 Heads Mixing Small Granules Multihead Weigher

Large Image :  32 Heads Mixing Small Granules Multihead Weigher

Product Details:
Place of Origin: Guangdong Zhongshan China
Brand Name: TOUPACK
Model Number: TY-A-M32-1; TY-A-P32-1
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 10-25 working days
Payment Terms: T/T, L/C
Supply Ability: 100set per month

32 Heads Mixing Small Granules Multihead Weigher

Description
Material:: Stainless Steel 304 Hopper Volume:: 0.8L/0.5L
Max. Speed:: 120 WPM Accuracy:: 0.1g
HMI:: 7'' / 10'' Color Touch Screen Control System:: MCU / PLC
Power Supply: AC220V ±10% 50HZ/60HZ, 2KW After Warranty Service: Video Technical Support, Online Support
High Light:

Small Granules Multihead Weigher

,

32 Heads Granules Multihead Weigher

,

32 Heads Mixing Weigher

32 Heads Mixing Weigher For Weighing Small Granules Products Multihead Weigher



Features :


1.Can use for 2 in 1, 3 in 1 and 4 in 1 mixing products.
2.More hopper to combination,higher accuracy
3.The weight of the mixing can be automatically compensated by the last products.
4.High accuracy and tailored load cell.
5.Intelligent alarm diagnosis.
6.High speed stagger dump function.
7.New Modular and CAN bus technology, more efficient and stable.
8.Modbus Industry communication protocol.



Techanical and Character :


1. Upper storage funnel is divided to weight two different products.
2. Separate main vibrator, control the thickness of product independently.
3. Integral machine frame and machine cabinet contributes to more stability and higher accuracy.
4. Uniform design standards, and mould processing, contribute to better interchangeability for spare
parts.
5. Stable actuator design reduce the mechanical vibration and improves the load cell value accuracy.





Specifications:



Model TY-A-M32-1; TY-A-P32-1
Max. Weighing (one hopper) 5-200g
Accuracy x (0.5)
Min. Scale Interval 0.1g
Max. Speed 120 WPM
Hopper Volume 0.8L/0.5L
Control System MCU / PLC
HMI 7’’ / 10’’ color touch screen
Power Supply AC220V ±10% 50HZ / 60HZ, 2KW
Packing Dimension 1,370(L)*1,060(W)*1,105(H)mm
Package weight 240kg






Detail:



32 Heads Mixing Small Granules Multihead Weigher 032 Heads Mixing Small Granules Multihead Weigher 132 Heads Mixing Small Granules Multihead Weigher 232 Heads Mixing Small Granules Multihead Weigher 3







32 Heads Mixing Small Granules Multihead Weigher 4



32 Heads Mixing Small Granules Multihead Weigher 5

32 Heads Mixing Small Granules Multihead Weigher 6
