10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control

10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control
10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control

Large Image :  10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control

Product Details:
Place of Origin: Guangdong Zhongshan China
Brand Name: TOUPACK
Model Number: M10L2.5
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 20-35 working days
Payment Terms: T/T, L/C
Supply Ability: 10set per month

10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control

Description
Application:: Snack Food, Dried Fruits Bag Type:: Pillow Bag, Gusset Bag, Hole Punching Bag, Vacuum Bag
Film Width:: 140-520mm Control Type:: Single Servo /dual Servo
Air Consumption:: 0.8Mps 0.5 M³/min Power Supply:: Single Phase 220V 50Hz/60Hz,2.2kW
High Light:

Popcorn Weighing And Packing Machine

,

Single Servo Weighing And Packing Machine

,

2.2kW Weighing And Packing Machine

10head VFF520 popcorn weighting and packing machine



Automatic Vertical Form Fill Seal(Vffs) Machine For Popcorn



10head VFF520 popcorn weighting and packing machine



10head VFF520 popcorn weighting and packing machine Product Description



Application

It is suitable to use in packing the high accuracy and easy fragile materals, such as: dry fruits, potato chips, crispy nice, snacks, candy,pistachio, sugar, apple slices, dumpling. chocolate, pet food, small wares, etcFeatures:

1. Double servo motors for film drawing down system.

2 Automatic film rectifying deviation function,

3. Famous brand PLC Pneumatic system for vertical and horizontal sealing

4. Compatible with different intemal and extemal measuring device5 Adopt clip supporting without broken bags and reduce waste



The entire Integrated system include the following machines:

1. Z conveyor and its feeder:


The conveyer is applicable for vertical lifting of grain material in departments such as corn, food, fodder and chemical industry, etc.

For the lifting machine, the hopper is driven by the chains to lift. It's used for vertical feeding of grain or small block material. It has advantages of large lifting quantity and highness.

The height of lifting: 360cm (discharging height 310cm)or others can be made according to customer's need.

Conveyor speed controlled by inverter. Bucket movement controlled by level sensor.
Max 90buckets/min

Power: 550W Voltage: 220V
Size: 3200x435x3650mm
Packing size: 1) main body:200x120x110cm=2.64CBM, about 300kg gross weight
2) vibration feeder: about 0.7CBM, about 100kg gross weight


2. 10 /14 heads multihead weigher:

10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control 0
Main Features
1) The most efficient and accurate weight calculation by computer.
2) Circle dump avoid materials drops together to avoid break and pile up
3) 10.1 inch touch screen with multiple languages.
4) Adjustable backlight control for vision protection
5) Compatible with single packaging machine for automatic weighing.
6) Instant hopper vibration index for better control.
7) 50 preset programs for multiple tasks.
8) Individual setting linear vibration amplitude
9) Templated motor drive, convenient for dismantling

Use rangeFood: Snack, candy, sugar, beans, chips, frozen food, sticky food, salad, pet food
Non food: small screws, buttons, nails, toys
Weight range:8g-1500g/dump
Max speed60bags/min
Weight accuracy±1g
Buckets10pc 1.5L weighing buckets
Operate language English, France, Spanish, Hungary, Germany, Finland.
Drive By step motor

3. Platform:
10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control 1


4. Vertical packing machine :
10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control 2

Features:
Suit for: OPP/CPP, CPP/PE, MST/PE and other types of heat sealing film
The touch-sensitive screen can display the state of machine, operation in struction and the state of breakdown in either Chinese and English, easy operation

It has a compact structure and every component has been made carefully, and the touching part of material are made by stainless steel

For guaranteeing stable ling-term operation of the machine, electrical equipments and pneumatic equipments are all made by famous manufacturers of the world

The date printer has an alarming equipment of no ink belt, without escaping printing.

Specification:

Packaging speed: 5-60bag/min
Bag making size: (L)50-300mm (W)60-200mm
Bag making type: pillow bag, vertical bag and make hole equipment (need to add extra money)
Filling range: 150-1300ml
Max packaging film width: 440mm
Film thickness: 0.04-0.08mm
Air consumption: 200L/min
Total power/ voltage: 2.2KW/220V, 50-60HZ
Outside size: 1400X970X1600mm
Gross weight: 400kg

Application:
Grain, strip and slice materials such as expanded food, shrimp cracker, candies, peanuts and popcorns.

Package for grain materials such as rice, salt, jelly, mung bean oatmeal and laundry powder.

Function:
The design of this machine is reasonable and elaborate. Its performance is stable and it is easy to handle. It can cut the edge of every single bag or every several joint bags according to specific requirement. All proceedings of feeding, measure, bag-making, date printing, filling, puffing, sealing, cutting and outputting finished products are finished automatically.


5. Discharge conveyor:
(stainless steel main frame and food class belt)
Feeding speed30m/minute
dimension2110×340×500mm
Voltage220V/45W
Packing size179x48x53cm
Net weight60kg
Gross weight85Kg

6. Rotary  table:

Our Rotary Turntables are fabricated in s/s making it suitable for the food, beverage, chemical clean rooms and pharmaceutical industry.

Made by 304 stainless steel

Diameter:1000-1200mm

Height: 70-80cm (with the leg, so can adjust the height)

Speed: adjustable, controlled by governer

Power:220V. 50hz or 110V 60HZ, 60W

Max speed: 14-25turns/min



10 Head VFF520 Popcorn Weighing And Packing Machine Single Servo Control 3



2002 to 2009,Founder of the company started his business by providing processing support, designing and manufacturing automation production lines to ABB, Siemens and ThyssenKrupp which are among Fortune 500 companies.

Since 2009, TOUPACK has been focusing on R&D, fabrication, marketing and sales of intelligent weighing and packaging machines as well as various kinds of automated control equipment. Being a high-tech and innovative company, TO-U has worked as a business partner with Guangdong Meiweixian (Zhongshan),Anhui Qiaqia (Hefei) and many other well-known packaging machinery and food companies by supplying them with automated and intelligent weighing and packaging solutions. To better serve our customers, TO-U has set up its after-sales service center in California, USA, wholly-owned substitute Hefei TO-U Intelligent Equipment Co., Ltd. in East China and offices in Sichuan and Shanghai.
