Name: 130WPM Chocolate Scale Multihead Weigher With 10 Inches Touch Screen
Brand: GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD
SKU: TY-M20L0.8
Price: 8.00 USD
Availability: InStock

Home > products > Blended Products Multihead Weigher >

130WPM Chocolate Scale Multihead Weigher With 10 Inches Touch Screen

Chocolate Scale Multihead Weigher

130 WPM Multihead Weigher

10 Inches Touch Screen Multihead Weigher

Place of Origin:

CHINA

Brand Name:

TOUPACK

Certification:

Model Number:

TY-M20L0.8

Request A Quote

Product Details

Main Frame:

SUS304

Accuracy:

±0.5g

Min.Scale Interval:

0.1g

Max.Speed:

130WPM

Bucket Volume:

0.8L

Control System:

MCU

HMI:

10 Inches Touch Screen

Power Supply:

AC220V ± 10% 50HZ / 60HZ, 1KW

Net Weight:

500kg

Gross Weight:

570

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

USD 15,000-USD1,8000.00

Packaging Details

Wooden case packaging, 2400L*1000W*1530H(mm), gross weight 200kg

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

1 set per 35 working days

Automatic PLC 20 Heads Blended Products Multihead Weigher

Get Best Price

video

Automatic Bulk Snack Food Packaging Machine Biscuit Cookies Gummy Bag Pouch Filling Machine Mutlihead Weigher Packing Machine

Get Best Price

video

Mixed Dried Fruit Heat Sealing Pouch Multi-Function Packaging Machines Frozen Dried Fruit Filling Sealing Machine

Get Best Price

video

Automatic Mixed Chocolate Packaging Filling Machine With Capping And Labeling Line Nut Snack Packaging Machine

Get Best Price

Contact Now

Product Description

Chocolate Scale / Multihead Weigher TY-M20L0.8 Main Function & Features:
1. Professional digital weighing module with high precision and good stability
2. Control system: MCU or PLC (optional).
3. Touch screen interface with different levels of authorized access; up to 16 different languages for choice; application
software upgraded through USB.
4. Factory parameters recovery function; 99 preset product parameters to meet different parameter program requirements.
5. Weighing hopper able to discharge in turn to effectively prevent products from blocking.
6. Weighing and counting function to meet diverse needs from customers.
7. Real-time display of amplitude of each vibration pan as well as product weight in each hopper to better monitor the running
status of the machine.
8. Machine body with SUS304/316 for option; IP65 dust and waterproof design.
9. Cleaning function: able to make the hoppers in opening state for easy daily cleaning and maintenance.
10. Two independent weighing system. With double upper storage hopper, double main vibrator and double discharge chute, two
different products can be weighed at the same by presetting two different operating parameters. It can also be used as a
normal 20-head weigher.

Specification
Model: TY-A-M20-1；TY-A-P20-1
Max Weighing (one hopper): 5-250g
Accuracy:x (0.5)
Max. Scale Interval:0.1g
Max. Speed:130 WPM
Hopper Volume:0.8L/ 0.5L
Control System:MCU / PLC
HMI:10’’ color touch screen
Power Supply:AC220V ±10% 50HZ/60HZ, 3KW
Packing Dimension:1,430(L)*1,430(W)*1,508(H)mm
Net Weight:500kg
Package weight:570kg
