High Quality 17 Inch HMI Automated Food X-Ray Inspector 70m / Min Food X Ray Inspection Systems
High-Quality X-Ray Inspection System Application:
It is used for detecting metallic and non-metallic material and defects in the food, chemical, and pharmaceutical industry. such as glass. ceramics, stones, bones, hard rubber, and plastic.
X-Ray Inspection System Features:
1. Up to 8 grades of image processing to achieve the best product adaptability and stability.
2. Able to shield edge, desiccant, canned food, and aluminum clamp for ham sausage.
3. X-ray leakage meets US FDA and European CE standards
4. Air conditioning and IP66.
5. Easy to dismantle and clean.
6. Optional rejection
X-Ray Inspection System Configuration:
- Frequency converter: Danfoss (Danmark)
- X-ray collector: Detection Technology(DT) (Finland)
- Industrial air conditioning: Pfannenberg (Germany)
- X-ray: VJ GROUP (USA)
- PLC: MITSUBISHI (Japan)
- Limit switch: OMRON (Japan)
High Quality X-Ray Inspection System Specifications:
| Model |
TTX-2417K100 |
TTX-4017K100 |
TTX-5026K100 |
TTX-6035K100 |
| X-ray Light Source |
150W/100KV |
210W/100KV |
350W/100KV |
| Detecting Width |
240mm |
400mm |
500mm |
600mm |
| Detecting Height |
170mm |
170mm |
260mm |
350mm |
| Accuracy |
SUS ball Φ0.3mm, SUS wire Φ0.2*2mm |
| Transfer speed |
10-70m/ min |
| HMI |
Germany 17 inch touch screen |
| Connectivity |
LAN Port, USB Port |
| Working environment |
Working temperature:-10℃~40℃(Cooling method: Air conditioned cooling),
Working humidity:30%~90%, No dewing (Humidity controlling: Anti-humidity device) |
| X-ray Leakage |
1 millisievert/hour |
| Protection method |
Lead-free protective curtain(easy for disassembling) |
| Alarming method |
Acousto-optic alarming |
| Power Supply |
AC220V ± 10% 50Hz(60Hz) 1.5kVA Max |
| Body Material |
SUS304 |
17-inch HMI Automated Food X-Ray Inspector / x ray detector for food
X-Ray Inspection System Details:
About us: Food X Ray Inspection Systems Automatic X Ray Detector Food Safety High Accuracy
Why choose us:
ㆍOver 12 years of weighing and packing machine design & manufacturing experience
ㆍOver 60 countries customers' choices
ㆍProfessional team with passion and diligence
ㆍAll-in-one stand service
After-sale services:
1. Manual / Videos of machine installation, adjusting, and maintenance are available for you.
2. If any problems happened, telecom or online face-to-face communication is available 24 hours.
3. Engineers & technician Engineers available to serve machines for your country.
4. The machine will have a 1-year warranty of the machine.
FAQ:
Q1: Are you a manufacturer or a trading company?
A: We are a manufacturer, we have a professional factory in Guangdong China
Q2. Do you sell accessories for products?
A: Yes. We have matched the parts for our testing equipment.
Q3. How about the packing for the product?
A: We take of wooden case and it is very safe.
Q4. Do you accept customer Logos and customized ones?
A: we accept kinds of customized logos for all of our products for customers.
Q5. What's your main product?
A: We are specialized in multi-head weigher, conveyor machine, packing machine, Metal detector, Check weigher and other related electronic products and machine
Q6. How about your after-sales policy?
A: Customer First. We have our own R&D team and we can offer tech support. All of our product's normal warranty is 12 months.
