Automated Optical Snack Food X Ray Inspection Systems

Automated Optical Snack Food X Ray Inspection Systems
Automated Optical Snack Food X Ray Inspection Systems Automated Optical Snack Food X Ray Inspection Systems Automated Optical Snack Food X Ray Inspection Systems Automated Optical Snack Food X Ray Inspection Systems Automated Optical Snack Food X Ray Inspection Systems

Large Image :  Automated Optical Snack Food X Ray Inspection Systems

Product Details:
Place of Origin: Guangdong Zhongshan China
Brand Name: TOUPACK
Certification: CE
Model Number: TTX-2417K100
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 10-25 working days
Payment Terms: T/T, L/C
Supply Ability: 30 sets per month

Automated Optical Snack Food X Ray Inspection Systems

Description
X-ray Light Source:: 150W/100KV Detecting Width:: 240mm
Detecting Height:: 170mm Accuracy:: SUS Ball Φ0.3mm, SUS Wire Φ0.2*2mm
Transfer Speed:: 10-70m/ Min HMI:: 17 Inch Colorful Touch Screen
Connectivity:: LAN Port, USB Port X-ray Leakage:: 1 Millisievert / Hour
System: Windows 7 Power Supply: AC220V±10% 50Hz(60Hz) 1.5kVA Max
High Light:

Snack Food X Ray Inspection Systems

,

Optical X Ray Inspection Systems

High Accuracy X-Ray Food Automated Optical Inspection Systems For Snack Confectionary Detecting CE Approval



Application:



It is used for detecting metallic and non-metallic material and defects in food, chemical, pharmaceutical industry. such as glass. ceramics, stones, bones, hard rubber and plastic.



Main Function & Features:



1. Up to 8 grades of image processing to achieve the best product adaptability and stability.

2. Able to shielding edge, desiccant, canned food and aluminum clamp for ham sausage.

3. X-ray leakage meets US FDA and European CE standards

4. Air conditioning and IP66.

5. Easy to dismantle and clean.

6. Optional rejection





Configuration:

  1. Frequency converter: Danfoss (Danmark)
  2. X ray collector: Detection Technology(DT) (Finland)
  3. Industrial air conditioning: Pfannenberg (Germany)
  4. X ray: VJ GROUP (USA)
  5. PLC: MITSUBISHI (Japen)
  6. Limit switch: OMRON (Japen)



Specifications:



Model TTX-2417K100 TTX-4017K100 TTX-5026K100 TTX-6035K100
X-ray Light Source 150W/100KV 210W/100KV 350W/100KV
Detecting Width 240mm 400mm 500mm 600mm
Detecting Height 170mm 170mm 260mm 350mm
Accuracy SUS ball Φ0.3mm, SUS wire Φ0.2*2mm
Transfer speed 10-70m/ min
HMI Germany 17 inch touch screen
Connectivity LAN Port, USB Port
Working environment Working temperature:-10℃~40℃(Cooling method:Air conditioned cooling),
Working humidity:30%~90%,No dewing (Humidity controlling: Anti-humidity device)
X-ray Leakage 1 millisievert / hour
Protection method Lead-free protective curtain(easy for disassembling)
Alarming method Acousto-optic alarming
Power Supply AC220V ± 10% 50Hz(60Hz) 1.5kVA Max
Body Material SUS304



Automated Optical Snack Food X Ray Inspection Systems 0Automated Optical Snack Food X Ray Inspection Systems 1

Automated Optical Snack Food X Ray Inspection Systems 2

Automated Optical Snack Food X Ray Inspection Systems 3Automated Optical Snack Food X Ray Inspection Systems 4Automated Optical Snack Food X Ray Inspection Systems 5
