Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing

Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing
Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing

Large Image :  Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing

Product Details:
Place of Origin: Guangdong Zhongshan China
Brand Name: TOUPACK
Certification: CE
Model Number: Liquid Filling Machine
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 10-25 working days
Payment Terms: T/T, L/C
Supply Ability: 30set per month

Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing

Description
Packaging Speed:: 5-30 Bpm Zipper Bags Bag Size:: 100-430(L)*80-300(W)mm
Sealing Type:: Straight Grain Pouch Bag Type:: Stand Up Pouch, Premade Pouch, Zipper Bag, Gusset Bag, Falt Bottom Punch
Air Consumption:: 5-8kgf/cm²; 0.4m³/min Type: Liquid Filling Doy Packer
Function: Filling, Sealing, Printing Material: Stainless Steel 304 Pouch Filling Machine
Atomatic Grade: Automatic Zipper Pouch Packing Machine Product Name: Mini Doy Packer
High Light:

30bpm Premade Pouch Filling Sealing Machine

,

Mini Premade Pouch Filling Sealing Machine

,

Liquid Premade Pouch Packing Machine

Mini Doypacker Premade Pouch Filling Sealing Machine for Liquid Filling MachineiPouch Filling Sealing Machine Oil Pouch Mini Doypacker Machine Standup bag Zipper bag

Mini Doypacker main features:

  1. Easy to operate and easy to replace the bag;
  2. Low maintenance cost;
  3. No bag prompting function;
  4. Self-diagnosis function of open the bag failed (The bag can be reused); In that case, the machine will not fill and seal, it will re-take the bag;
  5. Positioning (anti-dropping) function of hopper;
  6. Warning function of cartridge heater fault;
  7. Warning function of cylinder fault.

Mini Doypacker Premade Pouch Filling Sealing Machine for Liquid Filling Machine

Specification:



No Feature Description
1 Pouch material Multilayer composite Premade Bag e.g: PET/PE
2 Pounch type

3 side seal bag, stand up pouch, zipper bag, flat bottom pouch

3 Size range 80mm≤W≤300mm
100mm≤L≤430mm
4 Speed 0-15 bags/min
5 Sealing type Straight grain, pitch is1mm (Optional reticulate)
6 Sealing width 10mm(5--20mm can be customized)
7 Power supply 220V, Single-phase, 50/60HZ, 1.2KW
8 Air pressure 0.65Mpa
9 Air consumption 0.3m³/min (Standard machine, no additional function)
10 Packaging dimension 1860*600*1650mm(Export non-fumigation wooden case)



Pet food zipper pouch packing machine / premade pouch filling sealing machine

Mini Doypack Bag type



Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 0

Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 1Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 2

Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 3





Working flow:

giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product


Pet food zipper pouch packing machine applicable scope:

1. Block material: bean curd cake, fish, eggs, candy, red jujube, cereal, chocolate, biscuit, peanut, etc

2. Granular type: granular drug, capsule, seeds, chemicals, sugar, chicken essence, melon seeds, nut, pesticide, fertilizer

3. Powder type: milk powder, glucose, seasoning, washing powder, chemical materials, fine white sugar, pesticide, fertilizer, etc

4. Liquid type: detergent, rice wine, soy sauce, rice vinegar, fruit juice, beverage, tomato sauce, peanut butter, jam, chili sauce

5. Other bagging materials


Associated equipment with Mini Doypack Machine:

1. Elevator: inclined elevator, Z type elevator, bowl elevator, single bucket elecator, etc.

2. FiIlling machine: multihead weigher, linear weigher, auger filler, etc.

3. Working platform: adjustable platform, simple platform, etc.

4. Exit conveyor / Check weigher / metal detector / Rotable table


Pet food zipper pouch packing machine details:
Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 4
Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 5
Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 6

Office&Workshop:
Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 7Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 8Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 9Mini Premade Pouch Filling Sealing Machine 30 bpm For Liquid Packing 10


>Why choose us:



ㆍOver 12 years weighing and packing machine design & manufacturing experience



ㆍOver 60 countries customers choices



ㆍProfessional team with passion and diligence



ㆍAll-in-one stand service





After-sale services:



1. Manual / Videos of machine installation, adjusting, maintenance are available for you.



2. If any problems happened, telecom or online face to face communication available 24 hours.



3. Engineers & technician Engineer available to serve machines for your countries.



4. The machine will have 1 year warranty of machine.




FAQ:

Q1: Are you a manufacturer or a trading company?

A: We are manufacturer, we have professional factory in Guangdong China

Q2. Do you sell the accessories for products?

A: Yes. We have Match the parts for our testing equipment.

Q3. How about the packing for product?

A: We takes of wooden case and it is very safe.

Q4. Do you accept customer Logo and customized?

A: we accept kinds of customized and logo of all of our products for customers.

Q5. What's your main product?

A: We are specialized in multi-head weigher, conveyor machine, packing machine, Metal detector, Check weigher and other related electronic products and machine

Q6. How about your after-sales policy?

A: Customer First. We have our own R&D team and we can offer tech-support. All of our products normal warranty is 12months.
