Place of Origin:
Guangdong Zhongshan China
Brand Name:
TOUPACK
Model Number:
TYA-CW300 / CW400 / CW500
CW90 / CW120 / CW220 Food Industry Conveyor Belt Check Weigher Weight Checker
Application:
It is widely used in many industries such as electronics, pharmacy, food, beverage, health products, cosmetics, light industrial and agricultural products, etc. Not only is it used to check if a single finished product is within the preset target weight but also to check missing parts of a full carton (missing bottles, boxes, pieces, bags, cans, etc.)
Main function & Features:
1. Report Function: Built-in report statistics. Reports can be generated into EXCEL format and automatically generate a variety of real-time data. USB can store over-one-year statistical data and keep abreast of production status.
2. Interface Function: Standard reserved interface for convenient data management; able to communicate with PC and or other intelligent devices.
3. Centralized Control: Able to achieve centralized control by one computer / HMI to multiple check weighers.
4. Parameter Restore Function: Original program can be restored.
5. Versatility: Standardization of the whole machine as well as that of HMI to complete weighing operation for different kinds of products.
6. Easy to Change: Able to store a variety of recipes, convenient replacement of product specifications.
7. Simple Operation: WEINVIEW color HMI with intelligent and humanized design.
8. Easy Maintenance: Dismountable belts for convenient maintenance and cleaning.
9. Adjustable Speed: Frequency conversion control motor used to adjust the speed when necessary.
10. High Speed and Accuracy: Equipped with high precision HBM digital load cell for fast and accurate sampling.
11. Zero Tracking: Manual or auto clearing and dynamic zero tracking.
Specifications:
Model | TYA-CW300 | TYA-CW400 | TYA-CW500 |
Weighing Range | 10kg | 20kg | 30kg |
Weighing Accuracy | ±2g | ±5g | ±10g |
Weighing Resolution | 0.1g | 0.1g | 0.1g |
Max Speed | 65 WPM | 50 WPM | 30 WPM |
Belt Width | 300mm | 400mm | 500mm |
Weighing Belt Length | 450mm | 570mm | 1050mm |
Infeed/Outfeed Belt Lenght | 450mm/800mm | 570mm/Roller 930mm | Roller Rejector 800mm |
Power Supply | AC220V ±10%/1P/0.5KW | AC220V ±10%/1P/0.5KW | AC220V ±10%/1P/0.5KW |
Control System | High speed A/D sampling controller | High speed A/D sampling controller | High speed A/D sampling controller |
Pre-set Prod. No. | 99 | 99 | 99 |
Belt Height | 750±50mm | 750±50mm | 750±50mm |
Optional Rejector | Air Blower/ Swing Arm/ Pusher | Pusher | Pusher |
