|Applicable::||16 Head MCU Multihead Weigher Orange Weigher||Material::||SUS 304 MCU Weigher|
|Max. Weighing (one Hopper)：:||100-5000g||Control System：:||MCU / PLC Control System|
|HMI：:||7'' / 10'' Color Touch Screen||Power Supply::||AC220V/110V ±10% 50HZ/60HZ, 2KW|
|Feeding:||Food Grade Belt||Type:||16 Head MCU Multihead Weigher Orange Weigher|
|Hopper:||5.0L Hopper Multihead||Numbers Of Hopper:||16 Head MCU Orange Weigher|
5.0L Hopper Fruit Multihead Weigher,
MCU Orange Fruit Multihead Weigher,
16 Head Fruit Multihead Weigher
Exquisite 16 head vegetable and fruit combination scale, large capacity five liter hopper, stainless steel, waterproof
16 head MCU multihead weigher Orange Weigher For Scaling Fruits and Vegetables Oranges/Potatoes/Onions
Exquisite 16 head vegetable and fruit combination scale Application:
Suitable for fruits or vegetable such as oranges, applies, pears, onions, tomatoes, potatoes, ect which is fraigle and easy to damage on surface. Or sticky food like ready to eat food, oily food or fresh food.
Exquisite 16 head vegetable and fruit combination scale Technical Features:
1. Select the best combination immediately from diversified weight combinations through computer with perfect combination of high precision and high speed.
2. High precision data-type weighing sensor realizes precise weighing.
3. Liquid crystal screen operating system in multiple languages as Chinese an English. Etc.
4. IP65 degree water-proof and dust-proof design. It is clean and sanitary with all stainless steel parts. Full sealed design prevents accumulation of material and facilitates cleanng.
5. It can be fine the opening ad closing speed of hopper door according to the features of items to be weighed, and prevent crushing and blocking of material.
6. With powerful digital automatic counting function, it can record the index for each batch of product such as total bag number, pass rate, an difference of single bag, etc.
7. Optional devices: Feeding pans, dimple or plain plate, touch screen, stainless steel #316, etc.
Exquisite 16 head vegetable and fruit combination scale Specifications:
|Model||16 head MCU multihead weigher Orange Weigher|
|Max. Weighing (one hopper)||100-5000g|
|Min. Scale Interval||0.1g|
|Max. Speed||60 WPM|
|Control System||MCU / PLC|
|HMI||7’’ / 10’’ color touch screen|
|Power Supply||AC220V/110V ±10% 50HZ/60HZ, 2KW|
Spare parts: 1,480(L)*1,100(W)*1,238(H)mm
Spare parts: 330kg
16 head MCU multihead weigher Orange Weigher Details:
(1). Select the best combination immediately from diversified weight combination through computer with perfect combination of high precision and high speed.
(2). Special revolving vibration is better for scattering material.
(3). High precision data-type weighing sensor realizes precise weighing.
(4). It can be finely regulated the opening & closing speed of hopper door according to the features of items to be weighed, and prevent crushing and blocking of material.
(5). Dimple stainless panel can help to convey and avoid damaging the product.
(6). IP65 grade water-proof &dust-proof design. It's clear and sanitary with all stainless still parts.
(7). Displaying every vibration for working performance monitor.
(8). Presetting 99 sets of parameter for programming.
(9). Multilanguage to choose: Chinese, English, Spanish, Korea, German, French and Arabic, etc.
A 'typical target' weight per pack might be 100 grams of a product. The product is fed to the top of the multihead weigher where it is dispersed to the pool hoppers. Each pool hopper drops the product into a weigh hopper beneath it as soon as the weigh hopper becomes empty.
The weigher's computer determines the weight of product in each individual weigh hopper and identifies which combination contains the weight closest to the target weight of 100g. The multihead weigher opens all the hoppers of this combination and the product falls, via a discharge chute, into a bagmaker or, alternatively, into a distribution system which places the product, for example, into trays.
Dispersion is normally by gravity, vibration or centrifugal force, while feeding can be driven by vibration, gravity, belts, or screw systems.
An extra layer of hoppers ('booster hoppers') can be added to store product which has been weighed in the weigh hoppers but not used in a weighment, thus increasing the number of suitable combinations available to the computer and so increasing speed and accuracy.
Multihead weighing can help in the following ways:
The range of bags which can be filled using multihead weighers is immense. At one end of the scale are large catering packs of many kilogrammes. At the other are small bags of crisps which can be handled at high speed and efficiency.
Products containing up to eight components can be mixed on a multihead weigher, very accurately at high speeds. The weigher is divided into sections, each with its own infeed. For example, a breakfast cereal containing hazelnuts and dried fruit plus two relatively cheap ingredients, could be weighed on a multihead with say eight heads devoted to each of the more expensive components and four heads to each of the other two. This would ensure high weighing speed while ensuring that overfilling of the expensive ingredients was negligible.
Placing into trays
A well-engineered distribution system enables you to combine the speed and accuracy of multihead weighing with precise, splash-free delivery of product into trays.
