Name: SUS304 High Precision Check Weigher 0.1KW Belt Width 95mm For Medicine / Food
Brand: GUANGDONG TOUPACK INTELLIGENT EQUIPMENT CO., LTD
SKU: TY-CW90
Price: 6,750.00 USD
Availability: InStock

Home > products > Check Weigher >

SUS304 High Precision Check Weigher 0.1KW Belt Width 95mm For Medicine / Food

High Precision Check Weigher 0.1KW

Medicine Check Weigher SUS304

Food Checkweigher Machine

Place of Origin:

CHINA

Brand Name:

TOUPACK

Certification:

Model Number:

TY-CW90

Request A Quote

SUS304 High Precision Check Weigher 0.1KW Belt Width 95mm For Medicine / Food

Product Details

Main Frame:

SUS304

Accuracy:

±0.05g~±0.15g

Max Speed:

200 P/M

Belt Width:

95mm

Belt Length:

200mm

Power Supply:

AC 220V ± 10% / 1P / 0.1KW

Control System:

High Speed A / D Sampling Controller

Belt Height:

800±50mm

Optional Rejector:

Air Blower

Payment & Shipping Terms

Minimum Order Quantity

1 Set

Price

USD 6500-7000 per set

Packaging Details

Wooden case packaging, 2400L*1000W*1530H(mm), gross weight 200kg

Delivery Time

5-8 working days

Payment Terms

T/T

Supply Ability

1 set per 30 working days

250CC PE Vitamin Bottle 107*60mm Check Weigher

Get Best Price

200WPM Checkweigher Belt Conveyor With Drop Off Rejector

Get Best Price

Conveyor Belt CW90 CW120 CW220 Check Weigher

Get Best Price

950CC PE Candy Bottle 178*92mm Check Weigher

Get Best Price

Contact Now

Product Description

SUS304 High Precision Check Weigher 0.1KW Belt Width 95mm For Medicine/Food

Key Specifications

Attribute	Value
Main frame	SUS304
Accuracy	±0.05g~±0.15g
Max speed	200 P/M
Belt width	95mm
Belt length	200mm
Power Supply	AC 220V ± 10% / 1P / 0.1KW
Control system	High speed A/D sampling controller
Belt height	800±50mm
Optional rejector	Air blower

Product Overview

The SUS304 High Precision Check Weigher is designed for automatic weight verification of finished products in pharmaceutical and food industries, rejecting non-standard items with 95mm belt width and 0.1KW power consumption.

Key Features

Automatic zero tracking for consistent accuracy
Flexible adjustment for multi-specification product ranges
VFD speed control with wide regulating range
16-bit resolution with 0.05% measurement accuracy
Fast measurement time (20ms/50HZ or 33ms/60HZ)
Advanced storage and analysis capabilities (99 preset parameters)
High precision HBM digital load cell for accurate sampling

Technical Specifications

Warranty	1 Year
Applicable Industries	Manufacturing Plant, Food & Beverage Factory
Core Components	PLC
Weighing Range	200g
Weighing Accuracy	0.05g
Max Speed	200WPM
Certification	CE ISO
